High Accuracy H2S SO2 Gas Testing Chamber Controlled Environment Corrosion ISO17025
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | CE,RoHS,ISO17025 |
| Model Number: | SO-100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | USD8900 ~ USD28800 / SET |
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 5-14 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 360 sets / quarter |
|
Detail Information |
|||
| Name: | H2S SO2 Controlled Climatic Chamber | Volume: | 100L, 250L, 500L, 800L, 1000L, And More |
|---|---|---|---|
| Temperature: | 0℃ To +80℃ | Humidity: | 30% To 98% RH |
| Ozone Concentration: | 25+/-5 PPM | Internal Dimensions: | 450*450*500(mm) |
| Highlight: | aging test chamber,so2 test chamber |
||
Product Description
Controlled Environment Corrosion Noxious Gas H2S SO2 Controlled Climatic Chamber
Inner layer with glass fiber
High anti-corrosion ability
SO2 Exhaust device
IEC60068-2-42,IEC60068-2-60
Controlled Environment Corrosion Noxious Gas H2S SO2 Controlled Climatic Chamber relative humidity and noxious gas Corrosion to material, components and constructions. This test chamber can be used for single gas tests.
Controlled Environment Corrosion Noxious Gas H2S SO2 Controlled Climatic Chamber can be used to test SO2, H2S, HCL, NO, CL2.
| Name | Corrosion Noxious Gas H2S SO2 Controlled Climatic Chamber | ||
| Model | SO-100 | SO-225 | SO-500 |
| Internal dimensions (mm) | 400*500*500 | 500*600*750 | 700*800*900 |
| Overall dimensions (mm) | 860*1050*1620 | 960*1150*1860 | 1180*1350*2010 |
| Temperature range | 15 ºC ~ +80 ºC | ||
| Humidity range | 30％~98% R.H | ||
| Temperature fluctuation | ±0.5℃ | ||
| Temperature variation | ±2℃ | ||
| Humidity variation | ±2% | ||
| SO2 concentration | 25 ±5 ppm | ||
| Air change rate | 3 ~ 5 / hour | ||
| Controller | Programmable color display touch screen controller, Ethernet & USB | ||
| Interior material | Glass fiber reinforced plastics | ||
| Exterior material | Steel Plate with protective coating | ||
| Standard | IEC 60068-2-42 | ||
| Power & voltage | AC380V 50HZ | ||
▶Temperature control and display unit
▶Temperature accuracy 0.5℃
▶Programmable color LCD touch screen controller
▶Air cooled compression refrigeration system
▶USB and Eenet
▶Adjustable and removable sample shelves
▶Safety protection system
▶Different models
Test Area
Test area and door Interior made of glass fiber reinforced plastics.
Cabinet material is against harmful gas corrosion.
Cable hole as option
SO2 Exhaust Device
After test completed, click “ Exhaust” to exhaust SO2 from
test area to this exhaust device.
This dilutes SO2, to make workplace clean and safe
Control Panel
Programmable color display touch screen controller
Program: 100 groups in 999 sections
PC Link with software, R-232 interface
Regarding data record, if link to PC, data will be recorded to PC,
otherwise will be recorded on controller.
If data recorded on controller, can’t download, only see data.
Gas Sensor
High accuracy gas sensor
Valued by PPM, detecting for gas concentration inside of testing room
Sensor control accuracy: ± 0.1% FS
Sensor with calibration (Zero adjustment in a 99.99% nitrogen environment,stay in 15mins)
Easy to exchange the gas sensor
▶Export Standard Wooden Box
▶Can be used for Sea, Air, Railway, Truck transportation
▶Package size: 3.3 m³, gross weight: 410kg
Warranty & After Sales Service
3 Years Warranty, Lifelong Follow-up Services. We have a professional after-sales team, if you have any questions during operation, we will supply solutions to you with 24 hours.
Q: Do you have an agent?
A: Currently we have agents in Europe, Asia, North America, South Africa, and can provide sales and technical services.
Q: Can we come to your factory to study and train?
A: Welcome to our factory for study and training, we provide this service free of charge.
Q: Can you send engineers to our company?
A :Yes, sure. We will communicate in advance to facilitate the bringing of tools and components
Q :Can I install and debug calibration on site?
A :Yes, we can send technicians and engineers to the customer site for installation, commissioning and calibration.
Q: What are the modes of transportation?
A :Air, sea, rail, multimodal transport.
Q :What is the packaging?
A :Standard export wooden box packaging, solid and firm.
Q :How do you calibrate the equipment?
A We have our own calibration and third-party calibration such as ISO17025
Q: Is there a door to door service?
A :Yes, there is door to door service. We will arrange a one-stop service.
Q :What are the payment methods?
A :Payment methods are T/T, Paypal, L/C, VISA
