Temperature Testing Small Climatic Chamber 3 Years Warranty
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | RoHS,CE |
| Model Number: | TH-50 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 3-14 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal |
| Supply Ability: | 180 sets / quarter |
|
Detail Information |
|||
| Name: | Small Climatic Chamber | Low Type: | -20℃/-40℃/70℃ |
|---|---|---|---|
| Temperature Range: | -20℃ ～+150 ℃ | Warranty: | 36 Monthes |
| Humidity Range: | 20%~98% | Controller: | Programmable LCD Touch Screen |
| High Light: | Temperature Testing Small Climatic Chamber,98% RH Small Climatic Chamber,98% RH small temperature chamber |
||
Product Description
Description
LIB INDUSTRY focuses on development and production of small climatic chamber
, small temperature machine specifically testing the materials in resistance of heat, cold, dry and moisture. humidity testing machine is small size and not take up space.
Temperature and Humidity Range
Temperature Range:
●Type A:-20℃ ～+150 ℃.
●Type B: -40℃～+150 ℃.
●Type C:-70℃ ～+150 ℃.
●Type D:-86℃ ～+150 ℃.
Humidity Range:
20% ~ 98% RH
Parameters
| Name | Temperature Testing Small Climatic Chamber |
| Model | TH-50 |
| Internal dimension (mm) | 320*350*450 |
| Overall dimension (mm) | 800*1050*950 |
| Temperature range | -20℃ ～+150 ℃ |
| Low type | Ⅰ: -40℃ Ⅱ:-70℃ |
| Humidity range | 20% ~ 98% RH |
| Temperature fluctuations | ± 0.5 ℃ |
| Temperature deviation | ± 2.0 ℃ |
| Humidity deviation | ± 2.5% RH |
| Heating rate | 3 ℃ / min |
| Cooling rate | 1 ℃ / min |
| Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class |
| Temperature Resolution | ± 0.001 ℃ |
| Humidity sensor | Dry and wet bulb sensor |
| Power Supply | AC220V 50HZ |
| Environmental conditional | 5℃～+40 ℃ ≤85% RH |
Equipment Characteristics
 |
LCD touch screen controller, friendly interface, easy operation. |
|
small climatic chamber use environmentally friendly refrigerants |
1. Perfect design: the arc shape and surface coating processing, high body appearance, and USES the plane has no reaction, easy to operate, safe and reliable.
2. Large observation window: keep clear observation of the effect of the sample to observe the situation.
3. Temperature environment chamber,Water and electricity separation design, improve security.
