ASTM G155 Xenon Test Chamber Weathering Accelerated Aging Chamber
Product Details:
| Place of Origin: | China |
| Brand Name: | LIB |
| Certification: | CE,RoHS,ISO17025 |
| Model Number: | XL-750 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 14 days ( check if have stock) |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram，paypal |
| Supply Ability: | 120 sets / quarter |
|
Detail Information |
|||
| Name: | Accelerated Aging Chamber | Temperature Range: | Ambient ~100℃±2°C |
|---|---|---|---|
| BPT Temperature: | BPT +35 To +120 ℃ | Bandwidth Measurement: | 280nm~800nm |
| Certificate: | CE,RoHS,ISO17025 | Specimen Capacity: | 42pcs |
| High Light: | ASTM G155 Xenon Test Chamber,ASTM G155 Accelerated Aging Chamber,Weathering Accelerated Aging Chamber |
||
Product Description
ASTM G155 Weathering Accelerated Aging Chamber
Description
The LIB INDUSTRY accelerated aging chamber is mainly divided into 2 types, one is the UV accelerated aging chamber, which mainly uses ultraviolet light for aging test. The other is the xenon accelerated aging chamber, which mainly simulates the sunlight in the natural environment and conducts the aging test on the product.
You just need to tell us your needs, we recommend a suitable accelerated aging chamber for you.
Specification
|
Name |
ASTM G155 Weathering Accelerated Aging Chamber |
|
Model |
XL-750 |
|
Internal dimensions D*W*H |
950*950*850 mm |
|
Overall dimensions D*W*H |
1300*1420*1800 mm |
|
Specimen Capacity |
42pcs |
|
Specimen holder size |
95*200mm |
|
Irradiation Source |
1 piece of 6500 W water-cooled xenon lamp with inner quartz and outer borosilicate filter |
|
Irradiance Range |
100~1200 W/㎡ |
|
Bandwidth Measurement |
280nm~800nm |
|
Chamber Temperature Range |
Ambient ~100℃±2°C |
|
Black Panel Temperature |
BPT 35 ~85℃±2°C |
|
Relative Humidity Range |
50~98% R.H±5% RH |
|
Water Spray cycle |
1～9999H59M, adjustable |
|
Controller |
programmable color display touch screen controller, PC Link, R-232 interface |
|
Radiometer |
Tolerance: ±5% |
|
Heating system |
Nichrome heater |
|
Cooling system |
Mechanical compression refrigeration system |
|
Refrigerating unit |
French TECUMSEH compressor |
|
Humidification system |
External isolation, stainless steel surface evaporation humidifier |
|
Air circulation |
Centrifugal wind fan |
|
Water supply system |
Automatic water supply; Water purification system |
|
Safety device |
Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; |
|
Interior material |
SUS304 stainless steel |
|
Exterior material |
Steel Plate with protective coating |
|
Thermal insulation |
Polyurethane foam |
|
Observation window |
Interior lighting , double-layer thermo stability silicone rubber sealing |
|
Power Supply |
AC380V 50HZ |
Accelerated Aging Chamber
 |
xenon accelerated aging chamber
Irradiance Range:100~1200 W/㎡
Bandwidth Measurement:280nm~800nm
Chamber Temperature Range:Ambient ~100℃±2°C
Black Panel Temperature:BPT 35 ~120℃±2°C
Relative Humidity Range:50~98% R.H±5% RH
|
|
UV accelerated aging chamber Temperature Range:Ambient ～ 90 ℃ ±2℃ Black Panel Temperature (BPT):35 ～ 80 ℃ Bandwidth:290 ~ 400nm |
Feature
Weathering aging chamber
◆Inner box material:SUS304 high quality stainless steel light board
◆Sample holder material:SUS304 high quality stainless steel strip
◆Control system:Digital programmable temperature display
◆Safety system: protection for over-temperature, timing, overload and fan overheating
